10D602-60
VxWorks BSP for A602 and D602
VxWorks BSP for A602 and D602
10D602-60
VxWorks BSP (duagon) for A602 and D602
Lizenz-Informationen
Kosten
Kostenpflichtig
|
Ansprechpartner Vertrieb
Unterstützte Produkte
Previous
Next
Supported Operating System
VxWorks 6.7
Supported Hardware Features
- CPU
- IBM750CL (100 MHz front-side bus)
- IBM750GL (100 MHz front-side bus)
- Memory
- 512 MB triple redundant RAM
- 1 MB ECC protected FRAM
- 512 MB ECC protected FLASH
- I/O
- 7 serial ports
- Common IEEE 1149.1 connector via 08AE33- adapter
- Mezzanine Slots
- PMC1 slot for P511 Ethernet controller with one 10/100BASE-TX Ethernet port for evaluation and debugging
- Miscellaneous
- Real time clock
- NORTH FPGA DMA engine
- PPC decrementer used as auxiliary clock
- CompactPCI Interface
- CompactPCI Bus at 33 MHz
- VMEbus interface (A602)
Included Documentation
target.ref documentation
